Integrated Blade & Gutter Lighting
Recessed LED strips built into the blades and gutter line. Standard warm white, or upgrade to colour-changing.
Three louvre roof pergolas, engineered for Canterbury spans and wind loads - Manual for hands-on control, Motorised Light for motorised comfort with integrated lighting, Motorised Heavy for the big spans and highest wind rating. We supply and install every system ourselves, with our own crew from quote to sign-off - no walking away once it's up.
The Manual system is a manually adjustable aluminium louvre pergola. Open the blades for full sun and airflow, or close them flat for a weathertight roof over your deck or patio. It's built freestanding or fixed straight to the house, in Black, White or Charcoal, with drainage routed hidden through the posts.
Wind resistance rated 117-134km/h and backed by a 10-year structural warranty. Louvres are hand-adjusted with a crank handle mounted on the front post, and the hidden drainage runs down through the frame rather than external guttering. Footings and framing are sized to your span and site once we've been out for a measure.
Free on-site measure and quote, then we lock in your size, colour and mount type before ordering. We supply and install with our own crew - never a subcontracted kit - and hand it over with your warranty paperwork and a quick rundown of how to run the crank.
Aluminium doesn't need oiling or sealing - a wash with a soft brush and mild detergent keeps it looking new. Keep the hidden drainage channels clear of leaves and check the crank mechanism and fixings once a year, ideally before winter.
Manual adjustable louvre roof pergola
Price confirmed after on-site quote.
Motorised Light is our motorised aluminium louvre pergola. Open the blades for full sun and airflow, or close them flat for a weathertight roof over your deck or patio, all from a remote or your phone. Integrated LED lighting runs around the underside of the roof. It's built freestanding or fixed straight to the house, in Black, White or Charcoal.
Wind resistance rated 117-134km/h, the same as our manual system. Louvres are opened and closed by motor, controlled from a wall switch, remote or app rather than a hand crank. The LED strip is wired into the frame and runs on the same circuit. Footings and framing are sized to your span and site once we've been out for a measure, and every system carries our 10-year structural warranty.
Free on-site measure and quote, then we lock in your size, colour and mount type before ordering, plus the power run for the motor and lighting. We supply and install with our own crew - never a subcontracted kit - and hand it over with your warranty paperwork and a walkthrough of the remote and app.
Aluminium doesn't need oiling or sealing - a wash with a soft brush and mild detergent keeps it looking new. Keep the motor housing and hidden drainage clear of leaves, and get the motor and louvre seals checked once a year, ideally before winter.
Motorised louvre roof pergola
Price confirmed after on-site quote.
Motorised Heavy is our top-tier motorised louvre pergola, spanning up to 6 x 4m with no middle posts. 6063-T6 aluminium framing with an AkzoNobel powder coat, wind resistance rated 170-200km/h, and LED downlights integrated into every rafter. Open the blades for full sun and airflow, or close them flat for a weathertight roof, controlled by remote or app. It's built freestanding or fixed straight to the house, in Black, White or Charcoal.
Frame is 6063-T6 aluminium with an AkzoNobel powder coat finish, wind resistance rated 170-200km/h - the highest in our range. Louvres are motorised and run from a wall switch, remote or app, with LED downlights wired into each rafter on the same circuit. Footings and framing are sized to your span and site once we've been out for a measure, and every system carries our 10-year structural warranty. Estimated supply lead time is 6-8 weeks.
Free on-site measure and quote, then we lock in your size, colour and mount type before ordering, plus the power run for the motor and lighting. We supply and install with our own crew - never a subcontracted kit - and hand it over with your warranty paperwork and a walkthrough of the remote and app.
Aluminium doesn't need oiling or sealing - a wash with a soft brush and mild detergent keeps it looking new. Keep the motor housing and hidden drainage clear of leaves, and get the motor, LED wiring and louvre seals checked once a year, ideally before winter.
Motorised louvre roof pergola, higher wind zones
Price confirmed after on-site quote.
Popular add-ons for any of our louvre systems. Ask us to price these in at your free site visit.
Recessed LED strips built into the blades and gutter line. Standard warm white, or upgrade to colour-changing.
Wireless rain and wind sensors that close the roof automatically before a Canterbury nor'wester hits.
App and voice control, scheduled open and close. Available on our motorised systems.
Motorised or manual privacy and wind screens fitted to any open side.
Fixed, sliding or bifold aluminium side walls to fully enclose the space.
Framed or frameless glass panels for a wind break that doesn't block the view.
Louvre roofs fail for predictable reasons. Undersized framing that sags over a big span. Cheap aluminium blades that warp in the Canterbury sun. Drainage that leaks into the decking a year in. Motors under-specced for the blade count. Here's what we do differently.
Steel beams or heavy hardwood posts sized to the blade count and the wind load - not a one-size-fits-all kit. Large spans and nor'wester gusts handled without the roof flexing or sagging.
Every system we install is chosen and specced for the wind zone you're actually in, from manual entry points to our highest-rated motorised range. Marine-grade aluminium throughout, wind rated well beyond a standard fixed pergola.
Louvre frames designed to drain Canterbury rainfall properly. Gutter sized for the roof area, fall calculated, downpipes run to an appropriate outfall. No leaks into the decking.
We don't sell you a system and leave you to find someone to put it up. Same crew measures it, consents it, and installs it - and stands behind it for ten years.
Six stages from first phone call to the day the ten-year structural guarantee kicks in. No surprises on the invoice.
We come to you, walk the space, measure the proposed area. Talk through how you want to use it - entertaining, afternoon sun, winter shelter, year-round. We'll also check what you've got underneath (deck, paving, lawn, nothing yet) and whether the louvre will attach to the house or sit free.
We'll walk you through Manual, Motorised Light and Motorised Heavy based on your span, budget and whether you want manual or motorised control. Written quote through within the week, itemised so you can see where each line lands.
Attached-to-house louvres almost always need a building consent; free-standing louvres usually don't unless they breach Schedule 1 floor-area limits or boundary setbacks. We work out which side of the line your build sits on, lodge the consent if needed, and build your system to order once measurements are confirmed on site.
Posts set on structural piles or engineered concrete pad footings, depending on the build. Steel or hardwood beams rolled in for the span. Electrical rough-in for motor, lights, fan or heater done before the roof goes on.
Frame lifted into place. Blades installed and levelled. Gutters fitted, downpipes run to an appropriate outfall. Integrated LED strips and fan mounts finished before the blades are commissioned.
Motor commissioned and tuned. Remote and app (where the system supports it) paired and tested. Rain sensor calibrated if fitted. Manufacturer warranty documents, remote, and a walk-through handed over the day the job's done.
Every louvre install is quoted individually after a site visit. There's no flat per-square-metre rate because these variables move the number around - and the difference between a fixed pergola and a motorised opening louvre is significant.
Manual up to Motorised Heavy (motorised, biggest spans and highest wind rating) - each system is priced by size rather than a flat rate per square metre. See the size and price options above for exact numbers.
Area drives cost directly. Spans over about 5m without a mid-post need heavier framing - engineered steel beams instead of timber - which bumps the number up sharply.
Manual is cheapest; basic motor with remote is mid-range; full smart-home integration with rain sensor, app control and scheduled open/close is the top end. The motor spec also scales with blade count - bigger roofs need stronger motors.
Lights, heaters, fans and drop-down screens each add to the quote. All far cheaper to rough in at build time than retrofit a year later.
Attached louvres need wall flashing, load calculations on the existing structure and usually a building consent. Free-standing louvres need heavier footings for stability but often avoid the consent - different cost profile, different paperwork.
A louvre designed in from scratch is the cleanest build - posts land where they should and wiring runs where it needs to. Retrofit over an existing deck needs a structural assessment and often extra framing to handle the louvre load.
Straight answers to the things homeowners ask us most often. If your question isn't here, call John - he'll give you a straight answer, not a sales line.
Every install is quoted after a site visit, but here's a starting point: our Manual system starts from around $3,500, Motorised Light from around $4,400, and our largest Motorised Heavy system from around $9,200, all plus GST depending on size, colour and mount type. See the size and price options above, or the Pricing section below for what moves the number.
Manual if you're happy operating it by hand and want the most affordable opening roof. Motorised Light if you want full remote/app control plus integrated LED lighting over a mid-size span. Motorised Heavy if you need the biggest spans, the highest wind rating, or LED downlights built into every rafter. We'll confirm the right fit at the site visit.
Louvres attached to the house usually need a building consent. Free-standing louvres under the height threshold and outside certain boundary distances don't. We'll tell you on the site visit - and if a consent is needed, we handle the drawings, submission and inspections rather than leave it with you.
Usually yes. We'll survey the deck structure, check pile size and spacing, and work out whether the existing framing can carry the louvre load. Sometimes we add posts, sometimes we rebuild corners, sometimes the deck is ready as-is. Specialist work that a lot of louvre-only installers won't touch.
Most louvre installs run two to four weeks on site once the system arrives. Lead times from order are usually four to eight weeks depending on the system. Integrated builds (louvre designed into a new deck from day one) run four to eight weeks total on top of that.
We install across the Christchurch urban area and wider Canterbury - Halswell, Fendalton, Merivale, Redwood, Rolleston, Papanui, St Albans, Prestons, Marshlands, Rangiora, Ravenswood, Casebrook, Harewood, Redcliffs, Sumner, Kaiapoi, Ohoka, Cust, Yaldhurst, West Melton and everywhere in between. We also travel further across Canterbury and the wider South Island.
No. Manual, Motorised Light and Motorised Heavy are supply-and-install only - we don't sell the system as a kit for someone else to put up. Same crew measures it, consents it if needed, and installs it, backed by our ten-year structural guarantee. If you're after a DIY kit, we're not the right fit - but if you want it done properly and don't want to touch it again, that's exactly what we do.
Technically yes, practically no - you want them costed in from day one. Integrated lighting runs inside the blade and gutter line and looks clean; retrofitting it later means surface-mounted strips that look like an afterthought. Tell us what you want from the accessories above and we'll confirm exact costs at the site visit.
Every system - Manual, Motorised Light and Motorised Heavy - carries a 10-year structural warranty. Our own guarantee covers everything we built underneath and around it. Annual maintenance - running the motor, clearing gutters - takes about an hour.
Yes - that's often how we prefer to do it. Same crew, coordinated timeline, and the joins between deck, louvre, fence and retaining actually align because the same team set them out. See our deck building, fence builder and timber retaining wall pages for the rest.
Free on-site visits across the Christchurch urban area. For the right job we'll travel further across Canterbury and the wider South Island.
Free on-site quote. We come to you, walk the site, and send a written quote through within the week. No pressure, no hard sell, no follow-up spam.
